    Solar Hybrid Wechselrichter 5kw On Off Grid MPP Solar Hybrid Inverter

    Ask Lasest Price
    Brand Name : Deye
    Model Number : SUN-5K-SG04LP3-EU
    Price : US$+1800-2000+piece
    Payment Terms : T/T
    Supply Ability : 10000 pieces month
    Delivery Time : 10-15workday
    • Product Details
    • Company Profile

    Solar Hybrid Wechselrichter 5kw On Off Grid MPP Solar Hybrid Inverter

    Deye solar hybrid Wechselrichter 5kw 5000kw on off geid tie mppt 3 phase home system hybrid solar inverter SUN-5K-SG04LP


    ModelSUN-5K-SG04LP3-EU
    Battery Input Data
    Battery TypeLead-acid or Lithium-ion
    Battery Voltage Range (V)40~60V
    Max. Charging Current (A)120A
    Max. Discharging Current (A)120A
    Charging Curve3 Stages / Equalization
    External Temperature SensorOptional
    Charging Strategy for Li-lon BatterySelf-adaption to BMS
    PV String Input Data
    Max. DC Input Power (W)6500W
    PV Input Voltage (V)550V(160V~800V)
    MPPT Range (V)200V-650V
    Full Load DC Voltage Range350~650V
    Start-up Voltage (V)160V
    PV Input Current (A)13A+13A
    No.of MPPT Trackers2
    No.of Strings Per MPPT Tracker1+1
    AC Output Data
    Rated AC Output and UPS Power (W)5000W
    Max. AC Output Power (W)5500W
    Peak Power (off grid)2 times of rated power, 10 S
    AC Output Rated Current (A)7.6A
    Max. AC Current (A)11.4A
    Max. Continuous AC Passthrough (A)45A
    Power Factor0.8 leading to 0.8 lagging
    Output Frequency and Voltage50/60Hz; 3L/N/PE 220/380,230/400v
    Grid TypeThree Phase
    Current Harmonic DistortionTHD<3%(Linear load<1.5%)
    Efficiency
    Max. Efficiency97.60%
    Euro Efficiency97.00%
    MPPT Efficiency99.90%
    Protection
    PV Input Lightning ProtectionIntegrated
    Anti-islanding ProtectionIntegrated
    PV String Input Reverse Polarity ProtectionIntegrated
    nsulation Resistor DetectionIntegrated
    Residual Current Monitoring UnitIntegrated
    Output Over Current ProtectionIntegrated
    Output Shorted ProtectionIntegrated
    Output Over Voltage ProtectionIntegrated
    Surge protectionDC Type II/AC Type ll
    General Data
    Operating Temperature Range (⁰C)-45~60℃,>45℃ Derating
    CoolingSmart cooling
    Noise (dB)<45 dB
    Communication with BMSRS485; CAN
    Weight (kg)33.6
    Size(mm)422W×699.3H×279D
    Protection DegreeIP65
    Installation StyleWall-mounted
    Warranty5 years
