Name: Residential Low Voltage Hybrid Inverter GROWATT 5KW Inverter 48V SPF5000ES
Brand: Growatt
Price: 1029 USD

Add to Cart

Growatt Residential 48V Inverter Hybrid SPH 3000-6000TL BL-UP 3kw 4kw 5kw 6kw with 10years warranty

Specifications
Datasheet	SPH3000	SPH3600	SPH4000	SPH4600	SPH5000	SPH600 0
DC input data
Max. recommended PV power	6600W	6600W	6600W	8000W	8000W	8000W
Start voltage	150V
Max. PV voltage	550V
PV voltage range	120V-550V
MPPT voltage range /nominal voltage	150V-550V/360V
Max. input current of tracker A/B	12A/12A
Number of MPP trackers / strings per MPP tracker	2/1
AC Output
Rated AC output power	3000W	3680W	4000W	4600W	4999W	6000W
Max. AC apparent power	3000VA	3680VA	4000VA	4600VA	5000VA	6000VA
Max. output current	16A	16A	22A	22A	22A	27A
Nominal AC output voltage	230V
Nominal grid frequency	50/60Hz
Power factor at rated power	1
THDI	<3%
AC output power(Backup)
Max. output power	3000W
Rated AC output voltage	230Vac
Rated AC output frequency	50/60Hz
Automatic switchover time	<0.5S
Battery data
Battery voltage range	42~59V
Max. charging voltage	58V
Max charging and discharging current	66A
Max charging and dis charging power	3000W
Battery type	lithium /Lead-acid
Deep of discharging	80%DOD/50%DOD
Capacity of battery	3~12kWh
Efficiency
Max. efficiency	97.5%	97.5%	97.5%	97.6%	97.6%	97.7%
Euro European efficiency	97.0%	97.0%	97.0%	97.1%	97.1%	97.1%
MPPT efficiency	99.5%
Protection devices
DC switch	yes
DC reverse polarity protection	yes
Battery reverse protection	yes
Output over current protection	yes
Output over voltage protection	yes
Ground fault mon itoring	yes
Grid monitorin g	yes
Integrated all - pole sensitive leakage	yes
