Deye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230V

Ask Lasest Price
Brand Name :	Deye
Model Number :	SUN-3.6K-SG03LP1-EU
Certification :	IEC/EN 61000-6-1/2/3/4
Price :	US$+2600-2800+piece
Payment Terms :	T/T
Supply Ability :	10000 pieces month
Delivery Time :	10-15workday

Add to Cart

Product Details
Company Profile

Deye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230V

12KW Cheap price Deye Hybrid Solar Inverter 12KW SUN-12K-SG01LP1-EU AC 230V Single Phase for Home Solar System

Model	SUN-12K-SG01LP1-E	SUN-14K-SG01LP1- EU	SUN-16K-SGO1LP1-EU
Battery Input Data
Battery Type	Lead-acid or Lithium-ion
Battery Voltage Range (V)	40~60V
Max. Charging Current (A)	220A	250A	290A
Max. Discharging Current (A)	220A	250A	290A
UPS Power (W)	10000	12000	14000
Charging Curve	3 Stages / Equalization
External Temperature Sensor	Yes
Charging Strategy for Li-lon Battery	Self-adaption to BMS
PV String Input Data
Max. DC Input Power (W)	15600	18200	20800
Max. DC Input Voltage (V)	500
Start-up Voltage (V)	125
MPPT Range (V)	150~425V
Rated DC Input Voltage (V)	370
PV Input Current (A)	26+26+26
Max. PV ISC (A)	44+44+44
No.of MPPT Trackers	3
No.of Strings Per MPPT Tracker	2
AC Output Data
Rated AC OutputPower (W)	1200W	1400W	1600W
AC Output Rated Current (A)	52.2	60.9	69.5
Max. Continuous AC Passthrough (A)	100
Peak Power (off grid)	2 times of rated power, 5 S
Power Factor	0.8 leading to 0.8 lagging
Output Frequency and Voltage	50/60Hz; L/N/PE 220/230Vac (single phase)
Grid Type	Single Phase
DC injection current (mA)	<0.5% 1n
Efficiency
Max. Efficiency	97.60%
Euro Efficiency	96.50%
MPPT Efficiency	99.90%
Certifications and Standards
Grid Regulation	CEI 0-21, VDE-AR-N 4105,NRS 097,IEC 62116,IEC 61727,G99,G98 VDE 0126-1-1.RD 1699,C10-11
Safety EMC/Standard	EC/EN 61000-6-1/2/3/4,IEC/EN 62109-1,IEC/EN 62109-2
General Data
Operating Temperature Range (℃)	45~60°℃,>45°℃ Derating
Cooling	Smart cooling
Noise (dB)	<30 dB
Communication with BMS	RS485;CAN
Weight (kg)	48.5
Size(mm)	464Wx798.4H×300D
Protection Degree	IP65
nstallation Style	Wall-mounted
Warranty	5 years
